TP-Link AX1800 Wall Plate WiFi 6 Access Point
Interface:
• Uplink: 1× 10/100/1000 Mbps Ethernet Port
• Downlink: 3× 10/100/1000 Mbps Ethernet Ports (One port supports PoE OUT. The PoE OUT feature requires 802.3at PoE+ input.The maximum power output for POE pass-through is 13 W (EU version) or 12 W (US version), based on laboratory testing.)
Physical Security Lock: Yes
Power Supply: 802.3af/at PoE
Dimensions ( W x D x H ): 143 × 86 × 20 mm (5.6 × 3.4 × 0.8 in)
Antenna:
2 Dual-Band Antennas
• 2.4 GHz: 2× 3 dBi
• 5 GHz: 2× 4 dBi
Wireless Standards: IEEE 802.11ax/ac/n/g/b/a
Signal Rate:
• 5 GHz: Up to 1201 Mbps
• 2.4 GHz: Up to 574 Mbps
Warranty: 3 years
TP-Link AX1800 Wall Plate WiFi 6 Access Point
New Experience of Room Coverage with WiFi 6
Full Gigabit Ports to Bridge Network
Wired devices like VoIP phones can be powered with no need for extra electrical cables. The four data ports (1 uplink + 3 downlinks) transfer data at multiple Gigabits, allowing you to connect several devices to your gigabit network. One of the downlink ports offers PoE pass-through‡ to eliminate the need for that extra power port.
Superior WiFi 6 Speeds
Simultaneous 574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz totals 1775 Mbps Wi-Fi speeds
High-Performance Connectivity
Guarantee higher network efficiency and lower latency
Four Gigabit Ports
4 Gigabit Ethernet ports (1× uplink + 3× downlink), with one downlink port supporting PoE pass-through to provide power for wired device
High-Performance Connectivity for
Better User Experience
The latest WiFi 6 features and advanced wireless techniques guarantee higher network efficiency and lower latency.
Centralized Management
Integrates into Omada SDN for cloud access and remote management
Secure Guest Network
Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies
Easy Installation and PoE Support
Easy-to-install design, compatible with 86 mm & EU & US standard junction box, and 802.3af/at PoE support
