Right Power Titan PRO 1KR Rackmount UPS
Capacity: 1KVA / 900 W
Input
Nominal Voltage: 200/208/220/230/240VAC
Voltage Range: 120-300 VAC (Based on load at 50%) ; 180-300 VAC (Based on load at 100%)
Frequency Range: 40 Hz ~ 70 Hz
Phase: Single Phase with Ground
Power Factor: ≥ 0.99 @ Nominal Voltage (100% load)
Output
Output Voltage: 200/208/220/230/240VAC
Output Power Factor: 0.9
Voltage Regulation: ± 1 %
Frequency Range (Synchronized Range): 47~ 53 Hz or 57 ~ 63 Hz
Frequency Range (Batt. Mode): 50 Hz ± 0.25% or 60Hz ± 0.3%
Current Crest Ration: 3:01
Harmonic Distortion: ≤3 % THD (Linear Load) ; ≤ 6 % THD (Non-linear Load)
Waveform: Pure Sinewave
Tranfer Time (Inverter To Bypass): 4 ms (Typical)
Standard Model: 3 x IEC
Efficiency
Acmode: 88%
Battery Mode: 83%
Battery:
Battery Type: 12V / 9AH
Numbers: 2
Backup Time: 20 - 30 minutes depending on load
Typical Recharge Time: 4 hours recover to 90% capacity
Charging Current (Max): 1A
Charging Voltage: 27.4VDC ± 1%
Physical
Operating Environment: 0-40°C, 20 - 90% Relative Humidity (Non-Condensing)
Noise Level: < 50dB @ 1 Meter
Dimension (D x W x H (mm)): 310 x 438 x 88 (2U)
Weight (kg): 12
UPS Warranty: 3 Years Full Warranty Include Parts & Labour. 2 Years Warranty for Battery
Titan PRO Series
Titan PRO Series a high-density rackmount type true online double-conversion UPS design, come with output power factor 0.9. Titan PRO Series offer generator compatibility and deliver clean AC power with zero transfer time.
Titan PRO Series suitable for mission-critical applications and equipment’s. Comes with USB and RS-232 communication ports, built-in intelligent slot for additional adapters, protocol converters and relay contact cards.
FEATURES
Rackmount Type True Online UPS
Microprocessor Control Optimizes Reliability
User Friendly LCD Display
Output Power Factor - 0.9
Wide Input Range (110V - 300V)
Adjustable Battery Numbers
Converter Mode Available
ECO Mode Function for Energy Saving (1KVA - 3KVA)
Generator Compatible
Comes with RS 232 & USB Port, SNMP Slot and Power Management Software
Rear Panel
1. IEC Output Socket
2. Input Socket
3. Intelligent Slot
4. USB Communication Port
5. RS 232 Communication Port
6. Circuit Breaker
7. Terminal Block
8. External Battery Connector
