D-Link Smart Managed 24-Port Gigabit Switch
1000Base-T Interface: 24
Auto MDI/MDIX: Yes
10/100/1000BASE-T ports: 24
Switch Capacity: 48 Gbps
Max. Packet Forwarding Rate: 35.71 Mpps
Power Input: AC: 100-240V
Comply with RoHS 6: Yes
Energy Efficiency Ethernet (EEE): Yes
Power Saving By Link Status: Yes
Power Saving By Port Shut-Off: Yes
Power Saving By LED Shut-Off: Yes
Power Saving By System Hibernation: Yes
MAC Address Table Size: 8K
802.3x Flow Control: Yes
Head-of-line (HOL) Blocking Prevention: Yes
802.1D Spanning Tree (STP): Yes
802.1w Rapid Spanning Tree (RSTP): Yes
802.1AX Link Aggregation: Yes
802.3ad Link Aggregation: Yes
Max Port Per Link Aggregation Group: 8
Link Aggregation Group Per : 12
Port Mirroring: Yes
Loopback Detection (LBD): Yes
Jumbo Frame: 9216 bytes
IGMP Snooping: Yes
Max IGMP Snooping Groups: 64
802.1Q VLAN: Yes
VLAN Groups: 128
Port-based VLAN: Yes
Voice VLAN: Yes
Auto Surveillance VLAN: Yes
Asymmetric VLAN: Yes
Number of Queue: 4
Class of Service (CoS): Yes
Two Rate Three Color Marker (trTCM): Yes
Rate Limiting: Yes
Queue Handling: Yes
Strict Priority Queue (SPQ): Yes
Weighted Round Robin (WRR): Yes
Port-based Bandwidth Control: Yes
SSL: Yes
Broadcast/Multicast/Unicast Storm Control: Yes
D-Link Safeguard Engine: Yes
Traffic Segmentation: Yes
DoS Attack Prevention: Yes
Cable Diagnostics: Yes
Simple Network Time Protocol (SNTP): Yes
Web-based GUI: Yes
SNMP: Yes
SNMP Trap: Yes
TFTP Client: Yes
System Log: Yes
LLDP: Yes
D-Link Discover Protocol (DDP): Yes (v0.25)
Dual Images: Yes
DHCP/BootP Client: Yes
D-Link Network Assistant: Yes
Ping: Yes
Smart Wizard: Yes
Surge/Lightning Protection (AC Power Inet): 2kV
Surge/Lightning Protection (All Ethernet Ports): 1Kv
Store-and-Forwarding: Yes
Dimension: 280x 180x 44mm
Weight 1.47 Kg
Operation Temperature: -5-50°C
Storage Temperature: -40-70°C
Storage Humidity: 0% ~ 95% RH
Operation Humidity: 0%-95% RH
Operating Altitude: 2000 m
Maximum Power Consumption: 15.9 W
Standby Power Consumption: 4.5 Watts
Acoustic: 0 dB(A)
Maximum Heat Dissipation: 54.3 BTU/hr
MTBF: 424,762 hours
CPU Speed: 125MHz
Flash Memory Size: 16MBytes
DRAM Size: 128KBytes
Packet Buffer Size: 4.1 MBytes
FAN: Fanless
